WinTV v10 for the WinTV-unoHD Application Download

Installation notes for WinTV v10:

If you do not have a WinTV v10 Activation Code, you can purchase a new WinTV v10 Activation Code on the Hauppauge webstore.

If you have purchased an Activation Code for WinTV v10 with Extend from the Hauppauge Webstore, the latest version of WinTV v10 with Extend will be installed.

Installation on multiple computers: the WinTV application can be installed on as many PCs as needed as long as you use the same Hauppauge device. We link the serial number of your TV tuner (sometimes it's the MAC address) with the Activation code. So as long as you use the same Hauppauge device, you can install the WinTV application on more than one computer.

WinTV v10

This download is a complete WinTV v10 application, including Windows drivers for supported WinTV products plus utilities.

WinTV v10 installer
For Windows 11 and 10 (with limited support for Windows 8 and 7)
Version: 42130 | File size: 165 MB | Date: May 8, 2024
Release notes | Backup download site | Previous version 41041

New feature:

Record to network drive (NAS drive). When you enable this option, WinTV v10 will automatically move your recordings to a network drive after the recordings are complete, freeing up disk space on your PC.

*Please note: due to changes in Microsoft's code signing policy for Windows 7 and 8, new drivers cannot be signed for the 64-bit version of Windows 7 and 8. The WinTV v10 application will work, but the drivers will not install without warning messages.

WinTV v10 installation instructions

The WinTV v10 installer will install Windows drivers before installing the WinTV v10 application. It will also remove any pieces of a previous WinTV version before installing the new version.

Step 1: Download the WinTV v10 installer by clicking the download button above. The WinTV v10 installer is normally saved in the Download folder on your PC
Step 2: Run wintv10setup from the Download folder on your PC. If you see the message "Windows Protected Your PC, Windows Smartscreen prevented an unrecognized app ...", click 'More info' and 'Run anyway'. Windows Smartscreen is a new 'feature' in Windows 10 to prevent new updates from being installed automatically.
Step 3: Halfway through the installation, a message will pop up asking for you to enter the Activation Code.
Step 4: At the Activation required screen, click on Enter Activation code and enter the activation code which was emailed to you or is printed on the WinTV v10 activation card. You do not need to enter the dashes, and you can use upper or lower case characters.
Step 5: When the installation is complete, you will find the WinTV icon on your Windows desktop. Double click on this icon and the WinTV application will run. On the first run of WinTV, it will automatically go through the TV source selection and will scan for channels.

WinTV v10 installation instructions

The WinTV v10 will install Windows drivers before installing the WinTV v10 application.

Step 1: Download the WinTV v10 installer by clicking the download button above. The WinTV v10 installer is normally saved in the Download folder on your PC
Step 2: Run wintv10setup from the Download folder on your PC. If you see the message "Windows Protected Your PC, Windows Smartscreen prevented an unrecognized app ...", click 'More info' and 'Run anyway'. Windows Smartscreen is a new 'feature' in Windows 10 to prevent new updates from being installed automatically.
Step 3: Halfway through the installation, a message will pop up asking for you to enter the Activation Code.
Step 4: At the Activation required screen, click on Enter Activation code and enter the activation code which was emailed to you or is printed on the WinTV v10 activation card. You do not need to enter the dashes, and you can use upper or lower case characters.
Step 5: When the installation is complete, you will find the WinTV icon on your Windows desktop. Double click on this icon and the WinTV application will run. On the first run of WinTV, it will automatically go through the TV source selection and will scan for channels.

WinTV v10 Manuals

WinTV v10 Users Manual

WinTV v10 Frequently Asked Questions

How do I rescan channels?

Click on the setting button (Gear) in the lower left of the WinTV v10 application. Then click on the Devices tab and highlight your WinTV device and click Tuner Setup (see the first picture below).

In the Device Setup Wizard, you will see a list of TV formats which your Hauppauge TV tuner can support. Depending upon which Hauppauge tuner you have, you will have a choice of analog, digital or external inputs (see the second picture below). You can also select all formats and let the WinTV application show you what it finds in each format (if anything).

Click Next and Next and let WinTV scan for channels. The results should look like picture 3 below.

Settings -> Devices -> Tuner Setup

click to enlarge

Scan Complete

click to enlarge

My PC is not waking up for recordings. How can I fix this?

Windows 10 Wake settings

If recordings aren't happening at all, you need to make sure Wake Timers are enabled (see screenshot). You can find this setting in Power and sleep settings:
Power Options -> Change Advanced Power Settings -> Sleep -> Allow wake timers:
Control Panel\All Control Panel Items\Power Options\Edit Plan Settings
On my PC it was set to "Important Wake Timers only" and the PC wouldn't wake up for recordings.
